Bruker S1 Titan 800 Handheld XRF Analyzer
The S1 TITAN product line is entirely based on the latest detector technology. Every S1 TITAN model is equipped with a high-performance grap hene window silicon drift detector (SDD). As a result, users can expect to have fast, precise analysis regardless of the chosen S1 TITAN model.
The S1 TITAN is available in three high performance configurations, all sharing the same advanced detector technology: S1 TITAN 500, 500S, and 800
- The S1 TITAN 500 model is an excellent value choice when analysis of light elements is not required. It is designed for the simple and fast analysis of heavier elements, starting from sulfur.
- The S1 TITAN model 500S is the fast and easy-to-use analyzer which can measure both light and heavier elements simultaneously.
- The S1 TITAN 800 is the premium model with the best performance the widest application range and best light element performance for Mg, Al and Si.
Bruker S1 Titan 800 Handheld XRF Analyzer
Element Analysis from Magnesium to Uranium
S1 TITAN benefits at a glance:
- A wide range of calibration options are available: alloy, gold and precious metals, catalytic converters, soil, mining, restricted materials, metal coatings and customer specific
- Latest graphene window SDD detector technology
- Superior count rates and resolution
- Faster than previous generations
- Lower detection limits
- Easy analysis of light elements, such as magnesium, aluminum and silicon, without the need for vacuum or helium atmosphere (S1 TITAN 800 and 500S)
Bruker S1 Titan 800 Specifications
S1 TITAN Model 800 | S1 TITAN Model 500S | S1 TITAN Model 500 | |
---|---|---|---|
Detector | Graphene window SDD; 20mm2 active area; Typical resolution <145eV @450,000cps | ||
TITAN Detector Shield (TM) | Included on all models | ||
Size / Weight | 25 cm x 28 cm x 9 cm / 1.5 kg (with battery) | ||
Integrated camera | Optional on all models | ||
Elemental Range | Mg – U | Mg – U | Ti – U |
Collimator options | 8mm standard. 5mm or 3mm optional. | 8mm | 8mm |
Accessories Bruker S1 Titan 800
Protective Windows for Handheld and Portable XRF Analyzers
Protective windows, also known as “thin film”, is commonly used to protect the detector and other internal parts of a handheld XRF analyzer from dust and debris. Typical window materials include Ultralene(TM) and Kapton(TM). If an analyzer has vacuum capability, then gridded windows are offered to add strength to the windows so that the vacuum does not rupture the the window film.
Batteries for Handheld and Portable XRF Analyzers
P/N 160.0009 Lithium Ion Battery
7.2V Li-Ion instrument battery
Compatible with: S1 TITAN , TRACER 5
Quantity: 1 each
P/N 160.0145 Lithium Ion Battery
7.2V Li-Ion instrument battery
Compatible with: CTX
Quantity: 1 each
P/N 483100-550 Lithium Ion Battery
14.8V Li-Ion instrument battery
Compatible with: TRACER III, IV
Bruker S1 Titan 800 is lightweight (1.5 kg, including battery) and rugged handheld XRF analyzer. Fast analysis speed and exceptional accuracy are two key attributes that help define the S1 TITAN.
Other Innovative Features Include:
- 50 kV X-ray tube
- Latest graphene window detector technology
- TITAN detector shield – guaranteed detector protection
- SMART Grade timing for fast alloy grade ID
- Wi-Fi and USB connectivity
- An extremely tough housing that is sealed against humid and dusty environments
